abcOper.h File Reference

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Enumerations
enum	Acb_ObjType_t {   ABC_OPER_NONE = 0 , ABC_OPER_PI , ABC_OPER_PO , ABC_OPER_CI ,   ABC_OPER_CO , ABC_OPER_FON , ABC_OPER_BOX , ABC_OPER_CONST_F ,   ABC_OPER_CONST_T , ABC_OPER_CONST_X , ABC_OPER_CONST_Z , ABC_OPER_BIT_BUF ,   ABC_OPER_BIT_INV , ABC_OPER_BIT_AND , ABC_OPER_BIT_NAND , ABC_OPER_BIT_OR ,   ABC_OPER_BIT_NOR , ABC_OPER_BIT_XOR , ABC_OPER_BIT_NXOR , ABC_OPER_BIT_SHARP ,   ABC_OPER_BIT_SHARPL , ABC_OPER_BIT_MUX , ABC_OPER_BIT_MAJ , ABC_OPER_ABC ,   ABC_OPER_BA , ABC_OPER_BO , ABC_OPER_BX , ABC_OPER_BN ,   ABC_OPER_BAO , ABC_OPER_BOA , ABC_OPER_RED_AND , ABC_OPER_RED_NAND ,   ABC_OPER_RED_OR , ABC_OPER_RED_NOR , ABC_OPER_RED_XOR , ABC_OPER_RED_NXOR ,   ABC_OPER_LOGIC_NOT , ABC_OPER_LOGIC_AND , ABC_OPER_LOGIC_NAND , ABC_OPER_LOGIC_OR ,   ABC_OPER_LOGIC_NOR , ABC_OPER_LOGIC_XOR , ABC_OPER_LOGIC_XNOR , ABC_OPER_SEL_NMUX ,   ABC_OPER_SEL_SEL , ABC_OPER_SEL_PSEL , ABC_OPER_SEL_ENC , ABC_OPER_SEL_PENC ,   ABC_OPER_SEL_DEC , ABC_OPER_SEL_EDEC , ABC_OPER_ARI_ADD , ABC_OPER_ARI_SUB ,   ABC_OPER_ARI_MUL , ABC_OPER_ARI_SMUL , ABC_OPER_ARI_DIV , ABC_OPER_ARI_MOD ,   ABC_OPER_ARI_REM , ABC_OPER_ARI_POW , ABC_OPER_ARI_MIN , ABC_OPER_ARI_SQRT ,   ABC_OPER_ARI_ABS , ABC_OPER_COMP_SLESS , ABC_OPER_COMP_LESS , ABC_OPER_COMP_LESSEQU ,   ABC_OPER_COMP_MOREEQU , ABC_OPER_COMP_MORE , ABC_OPER_COMP_EQU , ABC_OPER_COMP_NOTEQU ,   ABC_OPER_SHIFT_L , ABC_OPER_SHIFT_R , ABC_OPER_SHIFT_LA , ABC_OPER_SHIFT_RA ,   ABC_OPER_SHIFT_ROTL , ABC_OPER_SHIFT_ROTR , ABC_OPER_NODE , ABC_OPER_LUT ,   ABC_OPER_GATE , ABC_OPER_TABLE , ABC_OPER_TRI , ABC_OPER_RAM ,   ABC_OPER_RAMR , ABC_OPER_RAMW , ABC_OPER_RAMWC , ABC_OPER_RAML ,   ABC_OPER_RAMS , ABC_OPER_RAMBOX , ABC_OPER_LATCH , ABC_OPER_LATCHRS ,   ABC_OPER_DFF , ABC_OPER_DFFRSE , ABC_OPER_DFFLAST , ABC_OPER_SLICE ,   ABC_OPER_CONCAT , ABC_OPER_ZEROPAD , ABC_OPER_SIGNEXT , ABC_OPER_LOGIC_IMPL ,   ABC_OPER_ARI_SQUARE , ABC_OPER_CONST , ABC_OPER_ARI_ADDSUB , ABC_OPER_LAST }
	INCLUDES ///. More...

Enumeration Type Documentation

Acb_ObjType_t

enum Acb_ObjType_t

INCLUDES ///.

CFile****************************************************************

FileName [acbTypes.h]

SystemName [ABC: Logic synthesis and verification system.]

PackageName [Hierarchical word-level netlist.]

Synopsis [External declarations.]

Author [Alan Mishchenko]

Affiliation [UC Berkeley]

Date [Ver. 1.0. Started - July 21, 2015.]

Revision [

Id

acbTypes.h,v 1.00 2014/11/29 00:00:00 alanmi Exp

] PARAMETERS /// BASIC TYPES ///

Enumerator
ABC_OPER_NONE
ABC_OPER_PI
ABC_OPER_PO
ABC_OPER_CI
ABC_OPER_CO
ABC_OPER_FON
ABC_OPER_BOX
ABC_OPER_CONST_F
ABC_OPER_CONST_T
ABC_OPER_CONST_X
ABC_OPER_CONST_Z
ABC_OPER_BIT_BUF
ABC_OPER_BIT_INV
ABC_OPER_BIT_AND
ABC_OPER_BIT_NAND
ABC_OPER_BIT_OR
ABC_OPER_BIT_NOR
ABC_OPER_BIT_XOR
ABC_OPER_BIT_NXOR
ABC_OPER_BIT_SHARP
ABC_OPER_BIT_SHARPL
ABC_OPER_BIT_MUX
ABC_OPER_BIT_MAJ
ABC_OPER_ABC
ABC_OPER_BA
ABC_OPER_BO
ABC_OPER_BX
ABC_OPER_BN
ABC_OPER_BAO
ABC_OPER_BOA
ABC_OPER_RED_AND
ABC_OPER_RED_NAND
ABC_OPER_RED_OR
ABC_OPER_RED_NOR
ABC_OPER_RED_XOR
ABC_OPER_RED_NXOR
ABC_OPER_LOGIC_NOT
ABC_OPER_LOGIC_AND
ABC_OPER_LOGIC_NAND
ABC_OPER_LOGIC_OR
ABC_OPER_LOGIC_NOR
ABC_OPER_LOGIC_XOR
ABC_OPER_LOGIC_XNOR
ABC_OPER_SEL_NMUX
ABC_OPER_SEL_SEL
ABC_OPER_SEL_PSEL
ABC_OPER_SEL_ENC
ABC_OPER_SEL_PENC
ABC_OPER_SEL_DEC
ABC_OPER_SEL_EDEC
ABC_OPER_ARI_ADD
ABC_OPER_ARI_SUB
ABC_OPER_ARI_MUL
ABC_OPER_ARI_SMUL
ABC_OPER_ARI_DIV
ABC_OPER_ARI_MOD
ABC_OPER_ARI_REM
ABC_OPER_ARI_POW
ABC_OPER_ARI_MIN
ABC_OPER_ARI_SQRT
ABC_OPER_ARI_ABS
ABC_OPER_COMP_SLESS
ABC_OPER_COMP_LESS
ABC_OPER_COMP_LESSEQU
ABC_OPER_COMP_MOREEQU
ABC_OPER_COMP_MORE
ABC_OPER_COMP_EQU
ABC_OPER_COMP_NOTEQU
ABC_OPER_SHIFT_L
ABC_OPER_SHIFT_R
ABC_OPER_SHIFT_LA
ABC_OPER_SHIFT_RA
ABC_OPER_SHIFT_ROTL
ABC_OPER_SHIFT_ROTR
ABC_OPER_NODE
ABC_OPER_LUT
ABC_OPER_GATE
ABC_OPER_TABLE
ABC_OPER_TRI
ABC_OPER_RAM
ABC_OPER_RAMR
ABC_OPER_RAMW
ABC_OPER_RAMWC
ABC_OPER_RAML
ABC_OPER_RAMS
ABC_OPER_RAMBOX
ABC_OPER_LATCH
ABC_OPER_LATCHRS
ABC_OPER_DFF
ABC_OPER_DFFRSE
ABC_OPER_DFFLAST
ABC_OPER_SLICE
ABC_OPER_CONCAT
ABC_OPER_ZEROPAD
ABC_OPER_SIGNEXT
ABC_OPER_LOGIC_IMPL
ABC_OPER_ARI_SQUARE
ABC_OPER_CONST
ABC_OPER_ARI_ADDSUB
ABC_OPER_LAST

Definition at line 41 of file abcOper.h.

             {
    ABC_OPER_NONE = 0,     // 00  unused
    ABC_OPER_PI,           // 01  input
    ABC_OPER_PO,           // 02  output
    ABC_OPER_CI,           // 03  combinational input
    ABC_OPER_CO,           // 04  combinational output
    ABC_OPER_FON,          // 05  output placeholder
    ABC_OPER_BOX,          // 06  box

    ABC_OPER_CONST_F,      // 07
    ABC_OPER_CONST_T,      // 08
    ABC_OPER_CONST_X,      // 09
    ABC_OPER_CONST_Z,      // 10

    ABC_OPER_BIT_BUF,      // 11
    ABC_OPER_BIT_INV,      // 12
    ABC_OPER_BIT_AND,      // 13
    ABC_OPER_BIT_NAND,     // 14
    ABC_OPER_BIT_OR,       // 15
    ABC_OPER_BIT_NOR,      // 16
    ABC_OPER_BIT_XOR,      // 17
    ABC_OPER_BIT_NXOR,     // 18
    ABC_OPER_BIT_SHARP,    // 19
    ABC_OPER_BIT_SHARPL,   // 20
    ABC_OPER_BIT_MUX,      // 21  fanins are: {Ctrl, Data1, Data0}
    ABC_OPER_BIT_MAJ,      // 22

    ABC_OPER_ABC,          // 23
    ABC_OPER_BA,           // 24
    ABC_OPER_BO,           // 25
    ABC_OPER_BX,           // 26
    ABC_OPER_BN,           // 27
    ABC_OPER_BAO,          // 28
    ABC_OPER_BOA,          // 29

    ABC_OPER_RED_AND,      // 30
    ABC_OPER_RED_NAND,     // 31
    ABC_OPER_RED_OR,       // 32
    ABC_OPER_RED_NOR,      // 33
    ABC_OPER_RED_XOR,      // 34
    ABC_OPER_RED_NXOR,     // 35

    ABC_OPER_LOGIC_NOT,    // 36
    ABC_OPER_LOGIC_AND,    // 37
    ABC_OPER_LOGIC_NAND,   // 38
    ABC_OPER_LOGIC_OR,     // 39
    ABC_OPER_LOGIC_NOR,    // 40
    ABC_OPER_LOGIC_XOR,    // 41
    ABC_OPER_LOGIC_XNOR,   // 42

    ABC_OPER_SEL_NMUX,     // 43  fanins are: {Ctrl, Data0, Data1, Data2, ...}
    ABC_OPER_SEL_SEL,      // 44
    ABC_OPER_SEL_PSEL,     // 45
    ABC_OPER_SEL_ENC,      // 46
    ABC_OPER_SEL_PENC,     // 47
    ABC_OPER_SEL_DEC,      // 48
    ABC_OPER_SEL_EDEC,     // 49

    ABC_OPER_ARI_ADD,      // 50
    ABC_OPER_ARI_SUB,      // 51
    ABC_OPER_ARI_MUL,      // 52
    ABC_OPER_ARI_SMUL,     // 53
    ABC_OPER_ARI_DIV,      // 54
    ABC_OPER_ARI_MOD,      // 55
    ABC_OPER_ARI_REM,      // 56
    ABC_OPER_ARI_POW,      // 57
    ABC_OPER_ARI_MIN,      // 58
    ABC_OPER_ARI_SQRT,     // 59
    ABC_OPER_ARI_ABS,      // 60

    ABC_OPER_COMP_SLESS,   // 61
    ABC_OPER_COMP_LESS,    // 62
    ABC_OPER_COMP_LESSEQU, // 63
    ABC_OPER_COMP_MOREEQU, // 64
    ABC_OPER_COMP_MORE,    // 65
    ABC_OPER_COMP_EQU,     // 66
    ABC_OPER_COMP_NOTEQU,  // 67

    ABC_OPER_SHIFT_L,      // 68
    ABC_OPER_SHIFT_R,      // 69
    ABC_OPER_SHIFT_LA,     // 70
    ABC_OPER_SHIFT_RA,     // 71
    ABC_OPER_SHIFT_ROTL,   // 72
    ABC_OPER_SHIFT_ROTR,   // 73

    ABC_OPER_NODE,         // 74
    ABC_OPER_LUT,          // 75
    ABC_OPER_GATE,         // 76
    ABC_OPER_TABLE,        // 77

    ABC_OPER_TRI,          // 78
    ABC_OPER_RAM,          // 79
    ABC_OPER_RAMR,         // 80
    ABC_OPER_RAMW,         // 81
    ABC_OPER_RAMWC,        // 82
    ABC_OPER_RAML,         // 83
    ABC_OPER_RAMS,         // 84
    ABC_OPER_RAMBOX,       // 85

    ABC_OPER_LATCH,        // 86
    ABC_OPER_LATCHRS,      // 87
    ABC_OPER_DFF,          // 88
    ABC_OPER_DFFRSE,       // 89
    ABC_OPER_DFFLAST,      // 90

    ABC_OPER_SLICE,        // 91
    ABC_OPER_CONCAT,       // 92
    ABC_OPER_ZEROPAD,      // 93
    ABC_OPER_SIGNEXT,      // 94

    ABC_OPER_LOGIC_IMPL,   // 95
    ABC_OPER_ARI_SQUARE,   // 96
    ABC_OPER_CONST,        // 97

    ABC_OPER_ARI_ADDSUB,   // 98

    ABC_OPER_LAST          // 99
} Acb_ObjType_t;
